LEMORAU SMART-L PREMIUM
Compact Digital Finishing Machine
Overview
Standard Features
Optional Equipment
Overview
Overview
Lemorau SMART-L Premium is a digital finishing machine that pairs servo-driven precision with a built-in flexo unit for varnish, color or foil. It offers full or semi-rotary die cutting for long and short runs, an Easy Strip waste removal system, and double rewinding for extra output flexibility.
Standard Features
Standard Features
- Web width 330 mm (13″)
- Max. rotary speed for blank labels: 200 m/min. (656 ft/min.)
- Max. rotary speed die cutting to register: 120 m/min. (394 ft/min.)
- Max. semi-rotary speed die cutting to register: 40 m/min. (131 ft/min.) with intelligent speed limit according to repeat
- Electronic Counter (Labels/ Meters/ Rolls/ Total meters and labels Counter / Information of current rolls diameters)
- Job memory for easy and quick job set ups
- Paper and matrix break detection
- QRC (Quick Remote Connection)- For fast and easy access to the machine remotely
- Automatic web tension control system by servo motors – Constant and Taper tension
- Smart Gap – Software compatible with all digital printers
- Multi language HMI touch screen
- Electrical supply according to destination country (no need of transformers)
- CE conformity certificated, user manual and electrical scheme
UNWINDER
- Servo driven with max. Ø 700 mm (27,5″), ID 76mm (3″)
- Automatic stop at master roll end with programmable roll-end settings
- Clockwise/counterclockwise unwinding
- Electronic web guide system with ultrasonic sensor and splice table with pneumatic clamps
FLEXO UNIT
- Smart concept flexo in semi-rotary/rotary mode
- Equipped with printing cylinder + anilox + UV curing system
DIE CUTTING
- Operates in full Rotary or Semi-rotary modes
- Die repeats in Rotary Mode: min. 203,20 mm (8″) – max. 431,80 mm (17″)
- Recommended die repeat in Semi-Rotary Mode (magnetic cylinder included Z130 1/8″): 82,55- 330,20 mm (3,25 – 13″)
- Servo driven buffer
- Deflation function for existing flexible dies in semi-rotary mode
- Easy Strip waste rewinder max. Ø 600mm (24″)
DIE CUTTING EQUIPPED WITH SPEED PACK (OPTIONAL)
- Maximum semi-rotary speed 80 m/min. – speed may vary depending on plate size
- Die repeats in Rotary Mode: min. 203,20 mm (8″) – max. 603,25 mm (23.75″)
- Recommended die repeat in Semi-Rotary Mode (magnetic cylinder included Z190 1/8″) 120,65 – 482,60 mm (4,75 – 19″)
SLITTING UNIT
- Cassette system equipped with 6 sets of circular knives with lateral adjustment
REWINDING
- Servo driven equipped with 1 interchangeable pneumatic rewinder, ID 76mm (3″)
- Semi-automatic rewinding (when having optional double rewinder)
- Clockwise/counterclockwise rewinding (labels in/ labels out)
- Max. rewinder Ø 580 mm (23″) using single rewinder / 350mm (14″) using optional double rewinder
Optional Equipment
Optional Equipment
- Additional mandrels in customized sizes
- Additional slitting knives
- Air trim removal
- Anvil roll with adjustable gap
- Automatic lubrication system
- Back scorer unit – manual/ automatic
- Bearer wipers & lubrication
- Clear on clear sensor
- Cold foil – full rotary
- Corona treatment
- Double rewinder
- IR / UV / UV LED curing lamps
- Foot Pedal
- Lamination – self wound or with liner
- Pressure gauges for die cutting unit
- Razor slitting knives
- Speed Pack Semi-rotary die cut up to 80m/min. (dependent on plate size)
Key Benefits
Combining precision finishing with an integrated flexo unit for varnish, one-colour printing or cold foil.
- Compact configuration with flexo
- Intelligent software & automation
- All-servo precision
- Fast & easy job changeovers
