LEMORAU CRM
Table Top Slitter/ Rewinder
Overview
Standard Features
Optional Equipment
Overview
Overview
Lemorau CRM is a compact, highly efficient table-top slitter rewinder built for precision and ease of use. Accurate web tension is controlled via a manual clutch and brake, with a splice table with pneumatic clamps for fast, effortless master roll changes.
Standard Features
Standard Features
- Web width 250, 330 mm (10, 13″)
- Maximum speed: 120 m/min. (398 ft/min.)
- Electronic Counter (Labels/ Meters)
- Variable web tension control
- Multi language HMI touch screen
- Electrical supply according to destination country (no need of transformers)
- CE conformity certificated, user manual and electrical scheme
UNWINDER
- Max. diameter 500 mm (20″)
- Pneumatic shaft ID 76mm (3″)
- Splice table with pneumatic clamps
SLITTING UNIT
- Equipped with 3 sets of circular knives with lateral adjustment – Can be added more as optional
REWINDING
- 1 interchangeable pneumatic shaft ID 76 mm (3″)
- Clockwise/counterclockwise rewinding (labels in/ labels out)
- Max. rewinder Ø 400 mm (16″)
Optional Equipment
Optional Equipment
- Additional mandrels in customized sizes
- Additional slitting knives
- Clear on clear sensor
- Electronic web guide system
- QRC (Quick Remote Connection)
- Razor slitting knives
- Waste rewinder
- Work bench
Key Benefits
A compact and practical solution for slitting and rewinding, also useful for changing roll direction and counting labels or meters.
- Precise slitting & rewinding
- Roll direction change
- Label & meter counting
- Compact & easy operation
