LEMORAU RA
Label Rewinder
Overview
Standard Features
Optional Equipment
Overview
Overview
Lemorau RA is an automatic rewinder with label and meter counters. Pneumatic shafts and tension control make it a great auxiliary machine for any label producer.
Standard Features
Standard Features
- Web width 250 mm (10″)
- 2 interchangeable pneumatic shafts ID 76mm (3″) in vertical position
- Unwinder max. diameter 450 mm (18″)
- Rewinder max. diameter 450 mm (18″)
- Label counter & Meter counter
- Tension Control
- Max speed up to 100 m/min. (328 ft/min.) depending on the roll diameter of the rewinder
- Rolls max. weight 40 kg (88 lbs)
- CE conformity certificated and user manual
Optional Equipment
Optional Equipment
- Additional mandrels in customized sizes
- Variable data inkjet printing system
- 1 printhead with 1 cartridge & Mini Touch Screen
- 1 printhead with 1 cartridge & 17″ computer
Key Benefits
A small but highly practical auxiliary machine for everyday roll-handling tasks that keep production moving.
- Rewind into smaller rolls
- Different core IDs on demand
- Label & meter counting
- Optional variable data printing
